10FEC390MT
Free Sample
Availability
Deliverable in short time
More information about samples availability can be found here: Availability
Ultra miniaturized 125°C THT Hybrid E-Cap FEC-series
Product Code:
329852
Weight: 0.8 g
Manufacturer: SUNCON
Weight: 0.8 g
Manufacturer: SUNCON
Detailed information
Ultra miniaturized 125°C SMD Aluminum-Polymer-Hybrid Electrolytic Capacitor 10FEC390MT with 4.000h guaranteed life time, low ESR and high ripple current capability.
For general questions
Technical Product Information
| Capacitance | 390µF |
|---|---|
| Capacitance Tolerance | +/-20 % |
| Max. Rated Ripple Curr.@100kHz | 4200mA rms |
| Impedance/ESR | 0.028Ω |
| Maximum Category Temperature | 125°C |
| Minimale Category Temperature | -55°C |
| Guaranteed Lifetime | 4000h |
| Pin Type | THT |
| Pitch | 2.5mm |
| Diameter | 6.3mm |
| Height | 7.2mm |
| Series | FEC |
| Voltage Type | DC |
| Rated Voltage | 10Vdc |
