10ZLG3300MEFC12.5x25
Free Sample
Availability
Deliverable in short time
More information about samples availability can be found here: Availability
105°C THT Ultra Low-ESR E-Cap ZLG-series for high ripple currents
Product Code:
259639
Weight: 4.8 g
Manufacturer: RUBYCON
Weight: 4.8 g
Manufacturer: RUBYCON
Detailed information
105°C THT Aluminum Electrolytic Capacitor 10ZLG3300MEFC12.5x25 with extra low ESR and extra high ripple current capability
For general questions
Technical Product Information
| Rated Voltage | 10V |
|---|---|
| Capacitance | 3300µF |
| Capacitance Tolerance | +/-20 % |
| Rated Ripple Current @100kHz | 2900mA rms |
| Rated Ripple Current @120Hz | 0mA rms |
| Impedance/ESR | 0,012Ω |
| Maximum Category Temperature | 105°C |
| Minimale Category Temperature | -40°C |
| Guaranteed Lifetime | 5000h |
| Pin Type | THT |
| Pitch | 5mm |
| Diameter | 12,5mm |
| Height | 25mm |
| Series | ZLG |
| Voltage Type | DC |
| Rated Voltage | 10Vdc |
